Description
3 Shaft Stretch Film Winder is a fully automatic PE stretch film/PVC cling film rewinding machine,this is upgraded model from the Italy automatic machine,with our own developed to be more of practical,user friendly,and cost effective in selling price.
Machine is with PLC program unit,LCD touch screen,premium inverter for simple operation,it is very user friendly.
The production rate will be improved by 30-50% to compare the convetional model.
The design speed is at 1500meter per minute for this model.
Technical data:
Material: PE stretch film/PVC cling film
Material: PE stretch film/PVC cling film
Mother roll width: max 500mm
Mother roll core:76mm
Mother roll outer diameter:500mm option
Finished roll core dia :1.5/2/3'' option
Finished roll max length:900mtrs option
Voltage:220/380/415/450v 3 ph
Power:4.0kw
Production speed:Max 1500m/min
3 Shaft Stretch Film Winder, High Speed 3 Shaft Stretch Film Rewinder, 3 Turret Stretch Film Rewinding Machine,
Pneumatic supply:0.3Mpa
Weight:1100kg
Other customzied demand is on option.
