630mm concentric type copper tape screening machine

Pinghu Digong
630mm concentric type copper tape screening machine
630mm concentric type copper tape screening machine

model: 630
drive type: groundshaft
structure: concentric type
MOQ: 1 set

Send Inquiry

Description

                                  φ630 Concentric Type

                          Copper Tape Screening Machine


Product application

Mainly used for screening copper tape of various types of cables.


Product Pictures

Product characteristics

1、Copper tape head uses concentric structure and high speed gearbox. Tapeout guide wheel has small rotating diameter. Even under high speed, the tape is still flat and stable.

2、Copper tape head has a chassis, and adopts pneumatic brake.


Product  components

Pay-off stand , well-shaped wire guiding stand, taping head, concentric type copper taping head, meter counter, caterpillar traction device, take-up and traversing stand, electronic control and safety protection device.


Technical parameters


1、Diameter of cable before screening:         φ80mm

2、Speed of copper tape:                          189-421rpm

3、Pitch of copper tape:                               8-184mm

4、Speed of taping head:                   189-421rpm

5、Taping pitch:                 18-184mm

6、Caterpillar traction:        1250kg

7、Outlet speed:         7.58-34.79m/min

8、Main motor power:   18.5kw

9、Take-up reel stand:    PN1250-PN2500


Product description
